TIG Cylinder Linear Seam Welding Machine

To cater to different customer workshop layouts and production needs, this equipment offers two configuration modes: "with trolley" and "without trolley":

• With trolley mode: Equipped with an independent mobile base or rail trolley, the equipment can be moved flexibly and is suitable for multi-workstation operations or scenarios requiring relocation due to space constraints.
• Without trolley mode: Utilizes a fixed bed design, with a compact structure and high rigidity, suitable for fixed-point batch welding on production lines, with a smaller footprint and superior operational stability.

Customers can flexibly choose the most suitable configuration based on their actual production scale, workpiece size, and workshop space.

Note: Non-standard customization is supported.

1.Frame and Moving Mechanism:

• With trolley: Utilizes a heavy-duty square steel welding carriage equipped with high-load-bearing casters and adjustable feet for easy movement. It can be quickly locked upon arrival at the workstation, ensuring stability during the welding process.
• Without trolley: Employs an integral welding bed, aging-treated for exceptional structural rigidity, ensuring no deformation under long-term heavy loads and guaranteeing welding precision.

2.Piano Key Type Clamping Mechanism:

• Employs a pneumatic piano key clamping plate design, using an independent clamping finger structure to achieve uniform clamping along the entire length of the workpiece. Combined with a back gas protection groove, it effectively prevents thermal deformation during welding, ensuring uniform weld back formation and preventing oxidation.

3.Welding Travel Mechanism:

• Utilizes high-precision linear guides and stepper/servo motor drive, ensuring smooth travel and stepless speed adjustment, guaranteeing the straightness and repeatability of the welding torch's trajectory during welding.

4.Welding Torch Adjustment Mechanism:

• Equipped with a three-dimensional manual/automatic adjustable slide, allowing for precise adjustment of the welding torch's up/down, left/right, and angle to adapt to welding requirements of different plate thicknesses and bevel types.

5.The electrical control system

• It adopts centralized PLC control and parameter setting via a touch screen. Multiple sets of welding process parameters can be pre-stored and recalled with a single button. It features safety operation functions such as "automatic welding," "jog welding," and "emergency stop reset."

Automatic TIG linear seam welding machine

CNC longitudinal seam welding machine

Welcome see more vedios ou our youtube channel: https://www.youtube.com/@HAOYUWelding

1.Normally we will use fumigation plywood case for packaging; for some big machine, we can use steel pallet and plastic filme cover.All machines are paint with anti rust paint or oil before leaving factory.
2.Package can be as customers' requirement.
