Description

Laser Cladding Welding Machine is an advanced welding equipment that uses high-energy laser beams to melt special materials (powder or wire) on the metal surface to form a high-performance coating. Its core is to achieve surface repair, strengthening or functional transformation by laser melting the substrate and cladding material.

Technical parameters

Item	YDGD-6000 parameters
Laser power	6000W
Powder feeder	Pneumatic split high precision powder feeder (9L)
Cladding head	Transmission coaxial annular cladding head (focal spot 3-5mm)
Six-axis robot	Arm span: 1820mm; Load: 20kg
Control System	PLC (with 10-inch touch screen)

Equipment installation conditions

Category	Requirmrnt	Consumption
Power	Three-phase power 380V ± 10%, 50Hz; single-phase power AC 220V ± 10%, 50Hz	The power consumption of the whole equipment is about 40KW
Energy	Protective gas: Argon/Nitrogen, conditional AP bottled argon or liquid argon	Consumption depends on the process
Cooling water	Laser and chiller use pure water	50L
Environment	Foundation requirements: cement strength ≥ C25; Foundation cement thickness ≥ 260 mm; Ground load: 5 tons/m2; foundation vibration: ≤ 0.5G; ambient temperature: 10-45℃; Acceptable temperature and humidity range: 40%-75%RH at 10-26℃; Electromagnetic radiation requirements: National Standard of the People's Republic of China GB8702-2014	NO

Advantages

Super wear resistance: cladding of tungsten carbide, cobalt-based alloy and other materials, high surface hardness
Precise repair: can be used to strengthen the edge and other easily worn parts, with super high repair accuracy
Matrix protection: small heat-affected zone to avoid tool deformation and performance damage
Economic and environmental protection: material utilization rate > 90%, reducing resource waste
