4 Axis Automatic Welding Machine For Cable Ladder

4 Axis Automatic Welding Machine For Cable Ladder

Welding Machine Main Characteristics: 1. Special welding solution for cable ladder 2. The machine is used for welding relatively complex seams. It has the features of accurate positioning, simple operation, uniform seam tracks and beautiful welding appearance, so that it can displace robot. 3....

4 axis automatic welding machine for cable ladder2

Welding Machine Main Characteristics:

1. Special welding solution for cable ladder

2. The machine is used for welding relatively complex seams. It has the features of accurate positioning, simple operation, uniform seam tracks and beautiful welding appearance, so that it can displace robot.

3. 4axis CNC, realize right&left,forward&backward,up&down and rotation movement.

4. Ladder is held and positioned by jig and fixture.

5. Machine is with high welding voltage and slow wire feeding performance, which guarantees reliable arc igniting. Machine is also with low welding voltage and low welding current for filling crater.

6. 4axis CNC system controls whole machine operation.Welding parameters and mode switch can be setup in one integrated control panel. System can save at least 100pcs welding programs.Programs can be directly called by inputting corresponding serial number.Programs can be locked with password.


4axis Welding Machine Parameters



4axis cnc

4sets servo motor

Welding power source

400A

Right&left moving range of welding torch

1500mm

Up&down moving range of welding torch

400mm

Welding torch rotation

0-360°

Up&down adjusting range of working station

300mm

Welding speed

100-1000mm/min
