Automatic Top And Bottom Skirts Beer Keg Welding Machine

Automatic Top and Bottom Skirts Beer Keg Welding Machine

I. Brief Description

• TIG welding without wire feeding

• Welding workpiece: 20L, 30L and 50L beer kegs

• Workpiece Thickness: 1.2-3mm

• Welding seam width: 1-4 mm

• Workpiece material: stainless steel

• Technical requirement: butt circular welding

• Welding requirement: complete automatic circular seam welding of the beer keg top and bottom skirts. Ensure concentricity, the appearance is uniform and good, depth and width of fusion meet the welding requirement.

II. Equipment Feature

• Welding torch is fixed, while the beer keg is rotating.

• The beer keg rotation chooses a single-drive synchronous rotating structure, to ensure the positioning of the beer keg and the consistency of the welding.

• The beer keg is clamped with a stop positioning structure. Hydraulic tailstock tightly presses beer keg. Ensure the concentricity of the two workpieces after clamping them.

• PLC is used to control the whole machine operation.

• The welding form, welding specifications can be preset, stored and recalled.

III. Welding Machine Parameters

IV. Equipment Composition

The machine consists of AC servo electric power head, fixture and conductive mechanism, adjustable roller workpiece bracket, hydraulic tailstock, positioning tool, welding torch pneumatic rapid advance and retract mechanism, adjustment mechanism, electrical control system, welding power source and so on.
