Product Introduction
Oil Cylinder Welding features its strong power and precise welding effects. It is mainly used to weld hydraulic cylinder circular seam automatically. This machine uses selected transformers and excellent solenoid valves. This machine is both cold and heat resistant, ensuring normal, consistent welding and cutting performance in a wide range of temperature. It also achieves efficient heat dissipation to ensure that the machine does not burn inside. This machine has longer service life and low after-sales maintenance rate, please rest assured to purchase.
Features
Oil Cylinder Welding is used to complete oil cylinder tubes, piston rod with eye, end caps and end plug circular seam welding. This machine applies PLC control in the whole operation with the rotation speed of workpiece adjusted, largely satisfying your different needs. In actual operation, you can also adjust many parameters to best reach your requirements. There is a welding operation platform, which is conducive to the operator to observe the weld.
The main body of this Oil Cylinder Welding adopts a welded structure, which has sufficient rigidity to ensure that it will not be deformed in long term of use. The welding torch is driven by a motor and a rack and pinion drive is used to move the carriage linearly. The walking speed of the welding torch can be adjusted steplessly, and the value is displayed on the control screen. This machine also has good energy saving function and sealing performance.
Product Parameters
Applicable cylinder diameter | 30mm-500mm |
Applicable cylinder length | 6000mm |
Rotation speed | 0.2-5rpm |
Motor power | 0.75kw |
Air compressor | ≥0.6Mpa |
Welding power source | 400A 500A |
Working voltage | 220v 380v |
